Electric Brake Backing Plate Assembly 12" x 2" 7000 lbs | AX-K12-1218-CH


Price valid while quantities last


Product Description

Self Adjusting Electric Brake is 12" x 2". Brake pads are made of durable friction material for improved braking and longevity. E-Coated backing plate resists rust. Fits 12-1/2", 15", 16" & 16-1/2" wheels.


  • Product # AX-K12-1218-CH
  • Weight: 14.68 lbs./ 6.66 kg.
  • Electric Brakes are easier to install and offer more user control than hydraulic brakes. Requires only an electric brake controller, no actuator or hydraulic lines necessary.
  • Automotive-grade friction material is molded to brake shoes.
  • Pads are fully bonded-not riveted-to shoes for long life and more braking torque.
  • Less chance of cracking and crumbling that can lead to mechanical lockup, thanks to tapered edge and circular grinding
  • Fine-tooth brake adjustment gear allows for a more precise setting
  • E-Coated backing plate resists wear and corrosion
  • Adjuster plugs (included) cover access holes to keep dirt and grime out of the assembly and off of the shoes
  • Mounting Bolts and Hardware (BRKH12S) sold separately
  • QAI and CSA Certified
  • Application: most standard hub-and-drum assemblies, including Dexter, Lippert (LCI), and AL-KO
  • Mounting Flange Bolt Pattern: 5 Bolt
  • Axle Rating: 5,200 lbs, 6,000 lbs & 7,000 lbs


  • Standard brake assemblies require manual adjustment of the brake shoes over time to provide longer-lasting and more efficient braking performance. With self-adjusting brakes, the brake shoes are always properly aligned, so there's no need to manually adjust the brakes after the initial adjustment. As a result, you get optimum performance without having to take the time to continually perform this type of maintenance.
  • This brake assembly meets the requirements for certification by the Canadian Standard Association (CSA).
  • Each shoe on this brake assembly is lined with automotive grade friction material for improved stopping performance and longevity. The friction material is fully bonded onto the surface of the brake shoe.


    • Diameter: 12-in.
    • Width: 2-in.
    • Wheel Size: 14-1/2in. 15-in. 16-in. 16-1/2-in.
